Test Cable Assembly Switch Cable LFH160 LFH200
Premier Cable make a lot of OEM Cables and LFH160 , LFH200 , 50 Pin D-Type cables for PXI Card, our cable is 100% compatible with original cable with very nice quality, fast delivery time
Category:
OEM Cables
Detail
| Key Words | LFH160 to 50-Pin D-SUB Cable LFH160 to 50-Pin D-SUB Cable LFH160 PXI Switch Cable SH200 LFH-4xDB50F-S Cable LFH160 to 50-Pin cable LFH160 Switch Cable |
| Product Name | Test Cable Assembly Switch Cable LFH160 LFH200 |
| Compatible Brand | National Instruments， Pickering Connection Division，Pickeringtest |
| Brand | Premier Cable , OEM |
| Connector | LFH160 , LFH200 , 50 Pin D-Type |
| Certificate | UL, Rohs, Reach |
| Gender | DB50 , LFH160, LFH200 Male , Female Connector |
| Cable | 28AWG*25 Pairs |
| Description | Premier Cable make a lot of OEM Cables and LFH160 , LFH200 , 50 Pin D-Type cables for PXI Card, our cable is 100% compatible with original cable with very nice quality, fast delivery time |
| Specification | SH200LFH-4xDB50F-S—Recommended for use with the PXI-2575 or SCXI-1175. SH200LFH-4xDB50F-C—Recommended for use with the PXI-2569/2570/2571 or SCXI-1169. SH200LFH-BARE WIRE—Recommended for termination other than 50-pin female D-SUB The LFH200 cable has a maximum voltage rating of 60 VDC. When using the LFH200 cable with switch modules, do not exceed 60 VDC" 4DB50F-LFH160F, SWITCH CABLE; Accessory Type:Switch Cable; For Use With:NI PXI-2576 and PXI-2530B Multiplexer Switch Modules; Product Range:4DB50F-LFH160F RoHS This unit is recommended for connecting the PXI-2575 or SCXI-1175 to your system. One end of the cable terminates with an LFH200 connector which connects to the switch module. The other end of the cable terminates with four 50-pin female D-SUB connectors. The cable in this kit connects an LFH200 connector to four, 50-pin female D-SUB connectors marked P1–P4, or eight bundles, leg J0–J7, of unterminated, tinned, and stripped wires. The LFH200 connector provides connection to the switch module. The 50-pin female D-SUB connectors and unterminated wires provide connection to your application. Figures 3 and 4 show the pinouts for these connectors |
| Application | Product Range : 4DB50F-LFH160F For Use With : NI PXI-2576 and PXI-2530B Multiplexer Switch Modules |
