120 Ohm RJ45 Bus Terminator Resistor CANOpen CAN RS485 DMX

Part Number:

PCM-0189

120 Ohm RJ45 Terminal Resistor is mainly used in differential signal communication systems that require impedance matching to reduce signal reflections, especially in long-distance communications, industrial environments or dedicated networks. These terminal resistors help improve signal stability and transmission quality.

Category:

RJ45 Cable


Products Description

Customizable

RJ45 Modular Plug Termination Resistor
RJ45 Bus termination resistor
ISDN terminating resistor RJ45
Modbus Terminator Resistor
CANOpen Termination Resistor
RS485 RJ45 Terminator Resistor
RJ45 DMX512 Terminator 120 Ohm
LED Lighting 120Ohm Terminator Resistor



Does RS485 need a 120-ohm terminal resistor?



Yes, RS485 communication usually requires a 120 ohm terminal resistor at both ends of the bus. This is to ensure the integrity and stability of the signal and avoid signal reflection at the end of the bus, which is especially important in long-distance, high-speed communications. RS485 CAN Bus Terminal Resistor 120 Ohm.

120 Ohm RJ45 Bus Terminator Resistor CANOpen CAN RS485 DMX



Why does RS485 need a 120 ohm terminal resistor?



1. Impedance matching:



RS-485 uses differential signal transmission, usually using twisted pair cables, whose characteristic impedance is about 120 ohms. Adding a 120 ohm terminal resistor at both ends of the bus can match the impedance of the cable and avoid signal reflection and data errors caused by impedance mismatch.


2. Prevent signal reflection:



Without a terminal resistor, the signal will be reflected back when it encounters an impedance mismatch at the end of the bus, causing communication signal distortion and data errors. The terminal resistor reduces interference on the communication line by absorbing the reflected signal.


3. Stability of long-distance communication:



RS-485 is often used for long-distance, multi-node communication, especially in industrial automation, building control, security systems and other fields. If the terminal resistor is not used, the signal will be attenuated and distorted during long-distance transmission, which will affect the communication quality.



LAN Termination Resistor RJ45 Terminator 8p8c 120Ohm


4. Installation location:



Install at both ends. Add a 120-ohm resistor to each end of the RS-485 bus (i.e. the two farthest nodes of the bus) to ensure stable signal transmission of the entire bus. There is no need to add terminal resistors to each node, just add them at both physical ends of the bus.



5. Exceptions:



In some short-distance communication or low-speed applications, if the cable is short enough (within a few meters), the reflection has little effect on the signal, and the terminal resistor can be omitted, but it is usually still recommended to install it to ensure better performance.




What Devices Use RJ45 Terminal Resistors?



1. Industrial Ethernet equipment: PLC (programmable logic controller), industrial switches, industrial routers and other equipment.



2. RS-485/RS-422 communication equipment (with RJ45 connector): controllers, sensors, monitoring systems, etc.



3. PoE (Power over Ethernet) equipment: PoE switches, PoE cameras



4. Long-distance Ethernet communication equipment: in Ethernet wiring exceeding the standard 100 meters



5. CAN bus equipment (with RJ45 connector): in-vehicle networks, industrial bus systems



6. Custom or dedicated network equipment: building automation control systems, security monitoring systems, audio/video distribution systems



RJ45 DMX512 Terminator 120 Ohm, ISDN terminating resistor RJ45
